Installation methods of different check valves
1. Swing check valve: The disc of the swing check valve is disc-shaped and rotates around the shaft of the valve seat passage. Because the passage in the valve is streamlined, the flow resistance is smaller than that of the lift check valve. It is suitable for large-diameter occasions with low flow rate and infrequent changes in flow, but it is not suitable for pulsating flow, and its sealing performance is not as good as that of lifting type.
2. Lifting check valve: a check valve whose disc slides along the vertical centerline of the valve body. Lifting check valves can only be installed on horizontal pipelines. For high-pressure small-diameter check valves, the disc can be made of balls. .
3. Disc check valve: a check valve in which the disc rotates around the pin shaft in the valve seat. The disc check valve has a simple structure and can only be installed on the horizontal pipeline, and the sealing performance is poor.
4. Pipeline check valve: a valve in which the valve disc slides along the centerline of the valve body. Pipeline check valve is a new valve. It is small in size, light in weight and good in processing technology. It is one of the development directions of check valve.
